Water Treatment

RO Water Purification Plant

Advanced reverse osmosis systems producing high-purity water for beverage production, food processing and bottled water plants — fully automatic multi-stage filtration.

Stages Pre-filter · RO · Post-treat
Control Fully automatic
Output High-purity process water
Product Overview

High-purity water for demanding industrial and beverage applications.

Our industrial reverse osmosis water purification plants are designed to produce consistent, high-purity water for beverage production, food processing, bottled water manufacturing and industrial process applications. The RO system removes dissolved salts, impurities, bacteria, heavy metals and contaminants from raw water — delivering clean, safe water that meets the quality requirements of your process.

The system uses a proven multi-stage filtration process: raw water passes through a sand filter to remove suspended solids, then an activated carbon filter to remove chlorine and organic compounds, followed by a cartridge filter for fine particle removal. The high-pressure pump then forces the water through the RO membrane array, which removes dissolved salts and microorganisms. Post-treatment options include UV sterilisation, ozone dosing and remineralisation.

All systems are supplied with a stainless steel pipeline and fittings, automatic control panel with water quality monitoring, and a storage and distribution system. We provide full installation, commissioning and operator training, along with ongoing membrane maintenance and chemical supply.

System Components

  • Raw water pump
  • Sand filter system
  • Activated carbon filter
  • Cartridge filter housing
  • High-pressure pump
  • RO membrane units
  • Control panel & monitoring
  • Storage & distribution system

Technical Specifications

ParameterSpecification
Production capacity500 L/hr – 50,000 L/hr (custom)
Salt rejection rate>97%
Recovery rate50–75% (feed water dependent)
Pre-filtrationSand filter + activated carbon + cartridge filter
RO membrane typeSpiral wound polyamide TFC
Operating pressure8–15 bar (feed water dependent)
Pipeline materialStainless steel / food-grade UPVC
Post-treatment optionsUV sterilisation / Ozone / Remineralisation
Control systemFully automatic PLC with water quality display
Chemicals usedAnti-scalant, membrane cleaner, pH adjustment
Power supply380V / 3-phase / 50Hz
Request a Quote

Need a water purification system?

Tell us your required output volume, water source and quality requirements — we'll size and design the right RO system.
